CONVENTIONAL EXCAVATORS

Don’t let their name fool you. KOBELCO conventional excavators are anything but. With high-quality construction and low-cost maintenance, they’re as cost-effective as they are dependable.

SK210HLC-10 Hybrid

  • Engine Power - 160 hp (119 kW)
  • Operating Weight - 52,500 lbs (23,800 kg)

The numbers don’t lie. The SK210HLC-10 boasts up to a 15% decrease in fuel consumption, a 7% increase in digging volume and an 88% decrease in NOx when compared to the standard SK210LC-10 machine. The KOBELCO SK210 Hybrid excavator uses lithium-ion batteries rather than capacitors, and is equipped with an electric swing motor that recharges the battery and assists the engine for digging and traveling as needed.

Overall Length31' 9" (9,670 mm)
Overall Height (to top of boom)10' 5" (3,170 mm)
Overall Width10' 9" (3,280 mm)
Ground Clearance of Rear End3' 6" (1,060 mm)
Ground Clearance18" (450 mm)
Tail Swing Radius9' 7" (2,910 mm)
Distance From Center of Swing To Rear End9' 6" (2,900 mm)
Tumbler Distance12' (3,660 mm)
Overall Length of Crawler14' 7" (4,450 mm)
Track Gauge7' 10" (2,390 mm)
Shoe Width2' 7" (790 mm)
Overall Width of Upperstructure9' 4" (2,850 mm)

PERFORMANCE

Travel Speed3.7 mph (6 kph) / 2.2 mph (3.6 kph)
Swing Speed12.7 rpm
Swing Torque51,900 lbf/ft (70.3 kNm)
Drawbar Pulling Force50,800 lbf (226 kN)

WEIGHT

Operating Weight52,500 lbs (23,800 kg)

ENGINE

ModelHino J05E UM
Power Output166 hp (124 kW)
160 hp (119 kW)
Max. Torque472 lbf (640 Nm)
Displacement312.6 in³ (5.123 ltr)
Fuel Tank84.5 gallons (US) (320 ltr)

HYDRAULIC SYSTEM

Pump 2 Variable axial piston + Gear
Max. Discharge Flow58.1 gallons(US)/min (220 ltr/min)
Max. Digging Reach32' 6" (9,900 mm)
Max. Digging Reach At Ground Level31' 11" (9,730 mm)
Max. Digging Depth22' (6,700 mm)
Max. Digging Height31' 11" (9,720 mm)
Max. Dumping Clearance22' 8" (6,910 mm)
Max. Vertical Wall Digging Depth20' (6,100 mm)
Min. Swing Radius11' 8" (3,550 mm)
Digging Depth For 8 Feet Flat Bottom21' 5" (6,520 mm)
Bucket Digging Force35,300 lbf (157 kN)
Arm Crowding Force25,200 lbf (112 kN)
