Don’t let their name fool you. KOBELCO conventional excavators are anything but. With high-quality construction and low-cost maintenance, they’re as cost-effective as they are dependable.
Perhaps the most versatile machine in the KOBELCO lineup, the next-generation SK350LC-11 excavator brings together superior performance and thoughtful design like never before. Performance enhancements offer great efficiency and productivity and increased speed and design improvements provide the ultimate in comfort and control. A new Isuzu Tier IV Final compliant engine delivers more efficient performance and a superior balance between engine output and torque. The new SK350LC-11 truly is a dream machine.
| Overall Height (to top of boom) | 12' 1" (3,690 mm) |
| Overall Width | 11' 1" (3,390 mm) |
| Ground Clearance of Rear End | 3' 11" (1,200 mm) |
| Ground Clearance | 19.3" (490 mm) |
| Tail Swing Radius | 11' 10" (3,600 mm) |
| Distance From Center of Swing To Rear End | 11' 10" (3,600 mm) |
| Tumbler Distance | 13' 3" (4,050 mm) |
| Track Gauge | 8' 6" (2,590 mm) |
| Shoe Width | 31.5 (800 mm) |
| Overall Width of Upperstructure | 10' 3" (3,120 mm) |
| Travel Speed | 3.7 mph (5.8 kph) / 2.2 mph (3.6 kph) |
| Drawbar Pulling Force | 71,900 lbf (320 kN) |
| Operating Weight | 84,200 lbs (38,200 kg) |
| Model | Isuzu 6HK1 |
| Power Output |
282 hp (210 kW) 265 hp (198 kW) |
| Max. Torque | 797 lbf (1080 Nm) |
| Displacement | 475.4 in³ (7.79 ltr) |
| Fuel Tank | 132.9 gallons (US) (503 ltr) |
| Number of Main Pumps | 2 |
| Max. Digging Reach | 36' 11" (11,260 mm) |
| Max. Digging Reach At Ground Level | 36' 3" (11,060 mm) |
| Max. Digging Depth | 24' 1" (7,350 mm) |
| Max. Digging Height | 35' 5" (10,790 mm) |
| Max. Dumping Clearance | 24' 9" (7,550 mm) |
| Max. Vertical Wall Digging Depth | 21' 7" (6,580 mm) |
| Min. Swing Radius | 13' 7" (4,140 mm) |
| Digging Depth For 8 Feet Flat Bottom | 23' 7" (7,200 mm) |
| Bucket Digging Force | 56,200 lbf (250 kN) |
| Arm Crowding Force | 40,700 lbf (181 kN) |
