Special jobs require specially equipped machines. KOBELCO has engineered these specialty excavators to take on unique applications that no ordinary excavator could touch.
The unique KOBELCO SK520LC-11 H&W is designed with the undercarriage of a High & Wide excavator and the upper structure of a Conventional excavator. With a wider stance, increased clearance, and larger boom cylinders, the SK520LC-11 H&W delivers superior stability and maximum lift capacity to increase jobsite performance.
Safety and convenience are prioritized with features such as a three-side camera safety system, all-around LED lighting, swing flashers, and an optional front cab guard. Additionally, the excavator offers complete compatibility with the KOMEXS telematics system, providing real-time monitoring and maintenance insights. Whether tackling construction projects or excavation tasks, the KOBELCO SK520LC-11 H&W is the ultimate partner on the jobsite.
| Overall Height (to top of boom) | 14' 1" (4,290 mm) |
| Overall Width | 13' 2" (4,020 mm) |
| Ground Clearance of Rear End | 5' 3" (1,600 mm) |
| Ground Clearance | 34.1" (865 mm) |
| Tail Swing Radius | 12' 9" (3,880 mm) |
| Distance From Center of Swing To Rear End | 12' 5" (3,790 mm) |
| Tumbler Distance | 14' 5" (4,400 mm) |
| Track Gauge | 10' 6" (3,190 mm) |
| Shoe Width | 31.5 (800 mm) |
| Overall Width of Upperstructure | 13' 5" (4,090 mm) |
| Travel Speed | 3.4 mph (5.4 kph) / 2 mph (3.2 kph) |
| Drawbar Pulling Force | 92,200 lbf (410 kN) |
| Operating Weight | 130,000 lbs (59,000 kg) |
| Model | Isuzu 6WG1 |
| Power Output | 463 hp (345 kW) |
| Max. Torque | 1460 lbf (1980 Nm) |
| Displacement | 956.9 in³ (15.68 ltr) |
| Fuel Tank | 190 gallons (US) (720 ltr) |
| Number of Main Pumps | 2 |
| Bucket Digging Force | 63,200 lbf (281 kN) |
| Arm Crowding Force | 52,400 lbf (233 kN) |
